CLYMER YAM 80-175CC PISTON-PORT 68-76 CM410

This Yamaha Vintage Motorcycle Manual is 168 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Service hints / Safety first / Tools / Expendable supplies / Mechanic's tips

CHAPTER TWO / PERIODIC MAINTENANCE
Engine tune-up / Spark plug / Compression test / Carbon removal / Breaker pints / Magneto ignition timing / Air cleaner service / Fuel strainer / Carburetor adjustment / Autolube pump adjustment / Battery service / Oil change / Clutch adjustment / Drive chain / Brakes

CHAPTER THREE / ENGINE, TRANSMISSION AND CLUTCH
Two-stroke operating principles / Engine lubrication / Preparation for engine disassembly / Engine removal / Cylinder and cylinder head / Piston, pin and rings / Reed valve / Flywheel magneto and starter/generator / Engine sprocket / Right crankcase cover / Clutch / Primary drive gear / Kickstarter / Tachometer drive gear / Shifter / Crankcase / Transmission / Crankshaft

CHAPTER FOUR / CARBURETORS
Carburetor operation / Carburetor overhaul / Carburetor adjustment / Miscellaneous problems

CHAPTER FIVE / ELECTRICAL SYSTEM
Flywheel magneto operation / Magneto troubleshooting / Capacitor discharge ignition (CDI) / Starter/generator / Lights / Horn / Main switch / Battery

CHAPTER SIX / CHASSIS SERVICE
Wheels / Brakes / Front fork / Steering head / Rear suspension / Drive chain

CHAPTER SEVEN / TROUBLESHOOTING
Operating requirements / Starting difficulties / Poor idling / Misfiring / Flat spots / Power loss / Overheating / Backfiring / Engine noises / Piston seizure / Excessive vibration / Clutch slip or drag / Poor handling / Brake problems / Lighting problems / Troubleshooting guide

APPENDIX / SPECIFICATIONS

INDEX

Wiring diagrams
