DALTON POLARIS RZR TURBO FLYWEIGHTS QPRZ-T

Adjustable weight tuner kit for 2022 and newer Polaris snowmobiles with the P22 primary drive clutch. (Boost turbo 850, 900R, etc.)

Dalton QP22 Series are a fully adjustable flyweight kit for the Polaris Boost and 9R models with the P-22 primary clutch. These weights were designed as a high-quality billet steel set that has more adjustment than earlier adjustable versions, allowing performance shops and pro racers to fine tune for their specific applications.

These new weights will, of course, incorporate the original “Dalton Quick Adjust” method that allows you to easily make fine tuning gram adjustments without even removing the flyweights from the drive clutch.

Note: for some 9R models that have a new updated billet spider, the Quick Adjust passage may not be able to be adjusted without removing the belt. The clutch sheave will have to be moved inward slightly because the new billet spider comes partially over the Quick Adjust hole in the flyweight when the vehicle is at rest.

The “Quick Adjust” passage allows you to add or subtract grams from the flyweight through the entry point at the heel by use of the supplied T-handle Allen wrench.

There is also independent threaded adjustment for the tip weight. The tip weight adjustment can be effective at changing both the total mass, and the location of mass on the flyweight.

This new design has some built-in heel type mass, and these models have a wider top design that allows for better belt grip as well as better wear resistance on the roller surface.

There are many combinations of added fasteners that add to the base weight to allow fine adjustment to the “total grams”, as well as different “placement of mass” combinations.

The threaded “Quick adjust passage”, as well as the “threaded tip hole” both have a bottom.

Even when using the smaller black “set screws” in the tip they will come to a stop and you should bottom them out.

The different base weights available should fill the needs of most applications. Each base weight can have up to 8.5 grams added allowing plenty of fine tuning adjustment, and allows for easy tuning in different forms (EG: tip heavy or heel heavy configurations).

The base weight indicates the weight of one base flyweight when empty.

QP22 base weights:

(please use part number for ordering)

472-QP2268 (68-76.5 g)

472-QP2271 (71-79.5 g)

472-QP2275 (75-83.5 g)

472-QP2278* (78-86.5 g)

472-QP2281** (81-89.5 g)

472-QP2284 *** (84-92.5 g)

* Popular for stock 850 Boost models at low elevation.

Popular for 850 Boost if performance aftermarket packages (pump gas/trail reprogrammed ECU, etc.) with extra boost and HP programs.

* more often for Higher HP/race fuel programs.

These are only notes and based on early feedback. Different clutch recipes in both clutches, as well as gearing, HP, etc. can alter the grams required.
