KOSO TNT-01R TACHOMETER WHITE FACE / CHROME CASING-H-D BA035102

TNT-01R Tachometer - 8 000 RPM for Harley-Davidson®

Built with the best components and strongest stepper motor on the market, this TNT-01R Tachometer is the perfect addition for all Harley-Davidson®. The TNT-01R tachometer's large dial face and backlight make it easy to read all day and night. Available in black or chrome casing.

TNT-01R | 8 000 RPM Tachometer | for Harley-Davidson® – chrome/white

Discontinued for reference only.

 Specifications
(R= Range U=Unit)

• Tachometer
  R: 0 ~ 8,000 RPM
• Internal display
  < 0.5 second
• RPM input signal number
  R: 0.5, 1 ~ 6
• RPM input pulse
  R: HI‑ACT (positive wave pulse)
  LO‑ACT (negative wave pulse)
• Backlight brightness
  R: 1/5 (darkest) ~ 5/5 (brightest)
• Effective temperature range
  14 ~ 140 °F (‑10 ~ 60 °C)
• Effective voltage
  DC 12 V
