RMS REGULATOR SUZ GS250-650|GSX-F750-1100 77-83 RM30302

RMS REGULATOR SUZ GS250-650|GSX-F750-1100 77-83 RM30302

Brand new aftermarket voltage regulator rectifier

• Direct replacement to your original unit.
• Plug-and-play, direct fit, easy installation.
• No assembly required
• Higher grade of electric components.
• The quality exceeds the OEM equipment
• All products shipped are tested

All item pictures are accurate, if in doubt do not hesitate and compare our item to your original part.

l part.

Specifications:

Dimensions:
Width: 50mm
Length: 75mm
Height: 25mm
Wires length: 230mm & 260mm
Fixation holes center to center: 55mm

Other specifications:
Number of plugs: 4
Number of pins: 5
Number of wires: 5
Minimum Charging Voltage: 13V +/- 0.5V
Maximum Charging Current: 6A-10A/50W-200W
Open Circuit Voltage: <15V
Operation Temperature: -20? to 85?

Warning:

Battery condition is extremely important. No voltage regulator can work correctly with a bad or weak battery. Always fully charge your battery before performing any charging system tests or replacing parts. If there is any doubt, have the battery load tested or replaced.
