All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.
Specifications:
Dimensions :
Interior diameter : 29 mm
Exterior diameter : 88 mm
Thickness : 10 mm
Length of wires stator to grommet : 110 mm
Length of wires grommet to plug : 325 mm
Length of pickup coil's wire to grommet : 30 mm
Other specifications :
Number of wires : 3
Number of plugs : 1
Number of pins : 3
Number of poles : 8
Wire to wire resistance :
Alternator #1 : Yellow to White = 0.5 ohms +-20%
Alternator #2 : Yellow to ground = 1 ohms +-20%
Alternator #3 : White to ground = 1.1 ohms +-20%
Pickup : Blue / Yellow to Ground = 104 ohms +-20%
Warning:
Battery condition is important. No stator can make up for a bad or weak battery. If in doubt charge your battery and have it load tested, or simply replace it. ALWAYS START WITH A FULLY CHARGED BATTERY !
